The new Sitrak C9H offers you flexibility with a high torque 660HP engine, drivelines and wheelbases in chassis configurations to meet your transportation requirements.
Leading safety features include a built in crumple zone, ABS, Camera, Radar Cruise Control and Lane departure warning.
Heated and cooled leather seats.
JOST JSK36 DV2 5th Wheel.
ZF 12 speed AMT gearbox.
Air suspension.
Discover the power, efficiency, and comfort of the Sitrak C9H 6x4 with a test drive. This truck delivers exceptional performance, fuel efficiency, and reliability—perfect for New Zealand’s toughest transport demands. Experience its smooth handling, advanced safety features, and driver-focused cabin firsthand.
Fill out the form below to book your test drive today!
JOST JSK36 DV2 5th Wheel
-
Bunk beds
12 Speed
GVM: 25,000kg
GCM: 90,000kg
TARE: TBA
Max load of two axles: (Front) 7000kg
Max load of two axles: (Rear) 18,000kg
Max speed: 100km/h
Min turning diameter: 16m
Max climb gradient: 35%
Fuel Tank Capacity: 550L + 450L
Model: C9-E
Seats: 2
Cab turning radius: 3640mm
Model: WP15H660E62A
Displacement: 15.3L
Power Rating: 660HP
Max Torque: 3200Nm @ 1200-1400r/min
Model: CH430-25 diaphragm
Operation mode: Hydraulic with air
Model: ZF12TX3221 TO
Forward gear ratio: 2.924,9.982,7.688, 5.938, 4.565,3.526, 2.831, 2.187,1.684, 1.301, 1,0.772
Reverse gear ratio: 12.033,9.293,2.636
Model: Trapezium frame
Main beam cross-section: 270mm x 85mm x 8mm
Width of frame assembly: (Front) 940mm
Width of frame assembly: (Rear) 762mm
Model: MCY13 Disc
Redactor ratio: 3.36
Redactor ratio: 2.85, 3.08, 3.7, 4.11
Differential Lock: Diff lock + cross lock
Model: VPD75 (Disc)
Front suspension model: Non-independent
Front suspension type: 3 Leaf parabolic
Rear suspension model: Non-independent
Rear suspension type: 8 Air bag
Model: Ball circle
Ratio: 22.2~26.2
Max pressure of pump: 18,300kPa
Working pressure: 1000kPa
Drive braking type: Dual circuit
Brake power adjust type: EBS + ESC + HSA
Parking brake type: Spring stored energy air cut brake
Assistant brake type: EVB
Circuit type: Double, control positive pole
Voltage: 24V
Generator power: 2.0kW
Batteries: 2x12V / 180Ah
Retarder: ZF retarder
Cabin: Sunvisor, side skirts
